EAO supports this need with the latest generation of seat reservation system with a standardised platform, that offers maximum flexibility in terms of customer-specific design and system adaptations. Not only can the system be easily and seamlessly integrated into the passenger information system but thanks to the innovative display technology and bright, clear, seat status indicators; passengers can easily locate a free seat, or find their prebooked seat reservation.

The EAO seat reservation system includes a modern, CAN bus-based, high-resolution display (SRD) and a matching gateway (SRG), which enables connection to the passenger information system (PIS) via Ethernet.

Advantages

• Early recognition of seat reservations thanks to bright LED indicators
• Increased passenger flow efficiency
• Energy-efficient, cost-effective and high-contrast display technology
• One display solution for flexible installation situations
• Seamless integration thanks to versatile customisation options

EAO’s seat reservation system was developed for the rail market and fulfils the specific norms and standards. Overall, the EAO seat reservation system represents a comprehensive solution for the requirements of rail transport. From straightforward installation to flexible adaptation to different seating arrangements and design requirements and with a focus on efficiency, we are setting new standards for the future railway travel experience.

Read more

With the seatback mounted SliderFLEX that holds the phone securely in either landscape or portrait mode and a table top mounted version, every seat can be provided with a charging service.

The innovative charging solution utilises a novel multi-coil inductive charger certified to the global Qi standard for iOS and Android that can charge any enabled phone wherever it’s charging interface is located – just by placing it in the SliderFLEX seatback holder, or on the table charging pad.

Wireless charging eliminates the need for cables and improves the reliability of the system, whilst the optional USB socket caters for older phones, or allows passengers to charge two devices simultaneously.

Key features

• Seatback mounted, or embedded tabletop charging units
• Wireless charging with Qi Inductive Technology
• Additional USB socket to charge two devices, or for charging older phones
• Can be retrofitted to seats and tables during refurbishment
• Rugged, reliable design for rail, tram and bus applications

Advantages for travellers

• They can charge their phone without the need for a power adaptor or a cable
• A charging service means they do not have worry about running out of battery charge

Advantages for rail operators

• Enhancement of the travel experience and operator image
• Can be retrofitted during repair work or as a separate improvement
• The reliable SliderFLEX holder wirelessly charges phones
• The service provider logo can be displayed

Charging Solutions are available in the following formats

Designs based on customer preferences are also possible:

• SliderFLEX design on the seatback for viewing in portrait or landscape format with a USB charging socket
• Round single-coil table charging station for installation into the table with a separate USB socket in the tablet edge (with standard cable and securing bracket)
• Rectangular multi-coil charging station with USB socket for flexible design options during installation
• Multi-voltage USB-C phone and laptop charging sockets

Typical applications

• CNC machines in the areas of milling, lathing, grinding and drilling
• Semiconductor and electronics production
• Industrial lifting and handling robots
• Cooling and ventilation technology
• Food and drinks sector
• Pharmaceutical and chemical industries production and process control
• Tobacco production and process control
• Textile production including systems for processing, drying, spinning and weaving
• Packaging systems
• Production lines
• And many more

Snap-on mounting and M12 connection technology

The Smart Box is mounted without special tools, by simply snapping it onto the mounting adapter. Thanks to the M12 connection, the Smart Box is operational in an instant. You also have the option of mounting the device directly on a standard DIN rail without the mounting adapter – this gives you flexibility in terms of the number and arrangement of Smart Boxes. The Bus connection or direct wiring alows for easy system integration.

Compatible actuators and indicators from EAO

The Smart Box works best with EAO’s fully compatible Series 84 indicators, illuminated push buttons and Emergency Stop switches. Further switching options are avialable on request. The robust design, combined with front protection up to IP67 enables reliable switching at temperatures from -25 °C to +70 °C (depending on the integrated products), in dirty or damp conditions, or in the event of vibration.

Individual front design with films

You have the option of adapting the front design for almost any application using a polyester film (e.g. for a customer logo or warning sign), a labelling plate, or an LED status display. If needed, EAO will integrate additional electronics functions onto a PCB or will equip and wire the Smart Box entirely in line with your preferences.

Advantages

• Easy snap-on mounting and M12 connection technology
• Multiple boxes can be flexibly mounted in series; robust and compact design
• Easy system integration thanks to Bus connection or direct wiring
• Front design and functionality can be customised
• Standard range – customer-specific solutions on request

We will also be happy to implement your individual solution

• Standard type with individual wiring: from 200 Smart Box units
• Standard housing with individual layout/in another colour: from 1,000 Smart Box units

Our experts will be happy to advise you.

Flexible, modular design

You can individually define the size of the operator panel, the symbols and the LED colours. The flexible number and arrangement of symbols and low back panel depth of less than 8 mm make it ideal for driver’s cabs and applications with limited space for display elements.

Typical applications

• Rail vehicles
• Industry
• Utility and special vehicles

Refined technology

For maximum safety in operation, any alarm display must be electrically independent; this also includes redundant illumination in every element. You control the display system via a Bus interface, digital inputs/outputs, CAN or other interfaces. You can easily and effectively integrate it into existing systems, and the display modules are available with dimmable illumination. The light test function with capacitive touch sensor in the alarm indicator is effective and responds immediately.

The wide selection of display symbols, grid spacing and symbols for each module make this status monitoring system even more flexible. If you would like to do so, you can mount the display panel using adapters or directly with mounting studs.

The multi-legend alarm indicator complies with EN 45545 and offers connection options for up to 36 symbols per module in a voltage range of 24 VDC to 110 VDC.

Advantages

• Adaptable control unit size and symbols
• Rapid adaptation to customer-specific requirements
• Additional functions can be integrated
• Ultra-thin design (< 8 mm), suitable for control units on driver’s cabs
• Bright, even illumination, visible in all light conditions

LED colours

• Red
• Green
• Blue
• Yellow
• White

Symbols

Can be defined on a customer-specific basis

As if by magic

The capacitive sensor door handle is an intuitive switching system. It activates electronic unlocking when a hand comes close to it or the active surface is touched, with the result that doors are very easy to open.

Conforms to TSI PRM

This modern door handle integrates perfectly into any design. New train generations in Europe in particular must comply with the TSI PRM technical specification; this defines the requirements for people with disabilities or restricted mobility in rail transport – including for universal toilets. This door handle fulfils those specifications. It activates electronic unlocking, meaning that the doors can be opened with minimal physical effort.

Intuitive LED status indication

An intuitive LED status indicator on the top end of the handle provides additional comfort. All metal parts on the sensor door handle are made from stainless steel. On request, EAO will customise the capacitive sensor door handle for your specific application, for example by using a shorter handle length.

Advantages

• Fail-safe, robust and vandal resistant
• Modern, simple design
• Easy actuation by touch
• Can be actuated when wearing gloves or with wet hands
• All metal parts are made from stainless steel
• Complies with the standard EN 50155

Technical data

• Supply voltage 24 VDC (± 30%)
• Operating power < 1 W
• Temperature range -40°C to +55°C
• High side switch
• Maximum load current 200 mA
• IP65 protection
